In the Pre-cure Tire Retreading process flow, after Initial Inspection, the tire’s old tread is mechanically removed on high speed buffers.Our buffers are extremely accurate and will remove the proper amount of old rubber while turning the tire to an exact specified diameter and radius.
Main Structure
This Tire Retreading Buffing Machine mainly consists of the Frame, Buffing Motor, Limit Control Motors, Lead Screw, and Curve Buffing Head, Wheel Chucks, Pneumatic Components and Electric Control Cabinet.
Tire Buffing Machine
Control Panel
Tires after Buffing
| Description | Specification |
|---|---|
| Machine Model | ML-FXM-F |
| Tire Sizes Suitable | 650-1200(15''-22.5'') |
| Dimension | 1600*1800*2100 mm |
| Electricity | 380V,50Hz,3Ph |
| Buffer Motor Power | 11 Kw |
| Turntable Motor Power | 2.2 Kw |
| Buffing Head Speed | 2980 r/min |
| Standard Wheel Chucks | 15''-16'',20''-22.5'' |
| Wheel Chuck Speed | 42 r/min |
| Front-to-Rear Limits Control Motor | 0.37 Kw |
| Left-to-Right Limits Control Motor | 0.55 Kw |
| Chuck Cylinder | spc100x400mm |
| Advantages | 1.Lifting Tyres Pneumatically Saving Labors 2.Easy Operation on Portable Control Panel 3.Over-Inflation Protection Function Designed for Safety 4.Rubber Granules Collected by Dust Collector 5.Accurate Buffer Saving Buffing Time 6..Optional for Tyre Shoulder & Sidewall Buffing Device |
As a tire retreading machines specialized manufacturing supplier who providing Turn-Key Service, Melion Industry company provides customers with complete solutions all the time, including professional marketing planning, production line procedure analysis, suitable raw materials supply, free technical training and so on.
Complete Set Tire Retreading Equipment Supplies:
Initial Inspection Machine, Buffing Machine, Dust Collector, Multi-functional Repair Stand, Extruder Machine, Cement Mixing Tank, Building Machine,Envelope Spreader,Rims Mounting Machine, Monorail, Curing Chamber, Pressure Test Machine etc.
